How to use Step and Repeat Program with a Gutter Trim:

Turn on the power to the cutter, wait until the backgauge moves back and will
recalibrate the position and this display appears:
NOTE: There will be a cursor (❑) flashing over at the last number, this is the work area.
C: 26"125
1: 00"00❑
Select a program number from 1-9, if you press (PROG)+(4) this screen appears:
C: 26"125
1: 00"00❑
If the first cut were at 8.75" and you would like to divide it into 2.0" name cards with a
0.25" trim in between for 4 times each, please do as follows:
Press (8)+(7)+(5)+(0) and (NEXT) , the following screen appears:
C: 26"125
1: 08"750
Press ( − )+(2)+(0)+(0)+(0) and (NEXT) and this screen appears:
C: 26"125
3: 00"00❑
Press ( − − )+(2)+(5)+(0) and (NEXT) and this screen appears:
C: 26"125
3: − 02"500
Press ( × )+(3) and (NEXT) the following screen appears:
C: 26"125
5: 00"00❑
PROG: 1
2: 00"000
PROG: 4
2: 00"000
PROG: 4
2: 00"00❑
PROG: 4
4: 00"000
PROG: 4
4: 00"00❑
PROG: 4
6: 00"000
