How to use Step and Repeat Program:

Turn on the power to the cutter, wait until the backgauge moves back and will
recalibrate the position and this display appears:
NOTE: There will be a cursor (❑) flashing over at the last number, this is the work area.
C: 26"125
1: 00"00❑
Select a program number from 1-9, if you press (PROG)+(3) screen appears:
C: 26"125
1: 00"00❑
If the first cut will be at 14.0" and you would like to divide it into 2.0" labels x 7, please
do the following:
Press (1)+(4)+(0)+(0)+(0) and (NEXT), the following screen appears:
C: 26"125
1: 14"000
Press ( − )+(2)+(0)+(0)+(0) and (NEXT) and this screen appears:
C: 26"125
3: 00"00❑
Press ( × ) (6) and (NEXT) and the screen will change to:
C: 26"125
3: ×
PROG: 1
2: 00"000
PROG: 3
2: 00"000
PROG: 3
2: 00"00❑
PROG: 3
4: 00"000
PROG: 3
06 4: 00"00❑
14
