Duplo Programatic Mark - II Operation Manual page 14

Move the backgauge to the third cut position, say 13.0" and make a cut, the following
screen is displayed:
C: 13"000
3: 13"000
After you finish storing all cuts, press
C: 13"000
3: 13"000
Press (END) it will beep 4 times, then re-press (END) to store the program and this
screen appears:
C: 13"000
1: 15"00❑
If you want to start cutting, press (AUTO), the backgauge will move to the first cut
position and the following screen appears:
C: 15"000
1: 15"00❑
Place your paper and make the first cut, after completing the cut, the backgauge moves to
the second cut position.
Adjust the paper for the 2
rd
3 cut position.
Adjust the paper for the 3
your stack automatically. Then it moves to the first cut position and readies itself for
next cut cycle.
After you have finished all cuts, press (AUTO) to remove the automatic backgauge
movement, AUTO will disappear on the display, and this screen appears:
C: 15"000
1: 15"00❑
PROG: 2 C&S
4: 00"00❑
CUT &
STORE
PROG: 2
4: 00"00❑
PROG: 2
2: 14"500
PROG: 2 AUTO
2: 14"500
nd
cut, after completion the cut, the backgauge will move to the
rd
cut & make your cut, the backgauge will then "push-out"
PROG: 2
2: 15"500
13
, the screen will change to:
