Others; Wall Tamper (Option) Connection; Led Light Pattern; Battery - Optex fit Series Installation Instructions Manual

5

OTHERS

5-1

WALL TAMPER (OPTION) CONNECTION

Connect the tamper connector as shown below
when connecting a wall tamper (option).
Separate box side Main unit side
Wall tamper (option)
WRS-03
5-2

LED LIGHT PATTERN

The following explains the LED light pattern.
LED
Blink
6

BATTERY

The detector shares the battery with the transmitter. Check that the 2.5 to 10.0 V power battery is used for the
transmitter.
6-1

HOW TO REPLACE BATTERY

Open the separate box, and disconnect the transmitter
1
connector. (It is not necessary for the main unit to be opened.)
Stacking method
Separate box
Separate
box cover
6-2

BATTERY LIFE

The values indicated are only for reference on condition that the detector is exceptionally operated by the sole battery.
It is impossible to indicate the battery life under the normal operation as the battery in the transmitter is shared with the
detector.
CR123A (3 V, 1300 mAh)
CR2 (3 V, 750 mAh)
1/2AA (3.6 V, 1000 mAh)
Mounting position
Stacking method
Warm-up
Notes>>
• The LED blinks even if the DIP
switch 4 (LED) is set to "OFF".
Light OFF
Alarm
Masking detection
(FTN-RAM only)
Side-by-side method and
top-to-bottom method
Separate box
3
Interval 120 sec
Approx. 6 years
Approx. 4 years
Approx. 5 years
Side-by-side method and top-to-bottom
method
Separate
box
Sponge
Detector condition
Replace the battery.
2
Separate
box cover
Connect the connector, and close
3
the separate box.
Note>>
• Check that the warm-up period
is started.
Notes>>
Interval 5 sec
Approx. 5 years
Approx. 3 years
Approx. 4 years
EN-9
Bracket
Sponge
LED indicator
120 sec.
Blinks for approx. 120 seconds.
2 sec.
Lights for 2 seconds.
Blinks 3 times and then repeats.
Red
Black
• Data shown here is when the LED is
off, AM is on. Battery life becomes
shorter when the LED is on.
