Summary of Contents for Kontron 104
- Page 1 V PANEL 104 / 121 / 150 / 170 / 190 User manual Rel. 08.2005 Ver.01 0-0096-3132 The German version of this manual is not available. Die deutsche Version ist nicht verfügbar.
- Page 2 V Panel 104 / 121 / 150 / 170 / 190 User Manual Manual History Date Version Changes Aug.2005 First edition Kontron Embedded Computers GmbH Werner-von-Siemens-Str. 1 93426 Roding Phone: +49 9461 950 -0 Fax: +49 9461 950 -100 e-mail: sales@kontron.com...
-
Page 3: Copyright
Kontron Embedded Computers GmbH (herinafter referred to as Kontron) ex- cept documentation kept by the purchaser for backup purposes. - Page 4 V Panel 104 / 121 / 150 / 170 / 190 User Manual ence to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by more of one or more of the following measures: 1.
-
Page 5: Table Of Contents
5.7 Block diagram ................33 Maintenance ..................34 6.1 Customer service ................34 6.2 Cleaning ..................34 6.3 Return and repair ................34 6.4 Packaging ..................35 Troubleshooting ................... 36 7.1 FAQ ....................36 Disposal ....................36 Appendix ....................36 http://www.kontron.com... -
Page 6: Introduction
- Software installation CD if implemented Carefully inspect each component to ensure that nothing is missing and/or damaged. If any of these items is missing or damaged, please contact Kontron immediately. Preserve of of the packing material for future transportation. - Page 7 • The power cord or plug is damaged. • Liquid has penetrated the Panel. • The Panel is exposed to moisture. • Obvious sign of breakage are visible. • System did not work properly or you can not get it work according to the application requirements. http://www.kontron.com...
-
Page 8: Overview
V Panel 104 / 121 / 150 / 170 / 190 User Manual 2. OVERVIEW The Kontron V Panel computer is a high performance system. The compact design enables an integration even under the condition of very restricted spaces. Our 100% industiy capable, scalable Panel meet the highest requirements concerning shock, vibration and temperature resistance. -
Page 9: Hardware Installation
Fig. 3-1 3.1.1 PS/2 Keyboard and Mouse Use this connector to connect PS/2 mouse and keyboard. 3.1.2 LAN1 Port This connector provides a external interfaces 10/100 BaseT on RJ45 to connect your Panel to other devices in a network. http://www.kontron.com... - Page 10 V Panel 104 / 121 / 150 / 170 / 190 User Manual 3.1.3 USB port This connector provides two external USB 2.0 interfaces 3.1.4 Parallel port LPT Use this port to connect a printer or other parallel devices. 3.1.5 Serial Interface COM1, COM2, COM3 Three serial interfaces enables you to connect a external device with 9 pin DSUB connector such as mouse or modem.
-
Page 11: Connect Internal Devices
+49 9461 950 - 0 Fax: +49 9461 950 - 100 3.2 CONNECT INTERNAL DEVICES The panel provides additional functions which could be implemented in the system by adding cards or changing the configuration of your Panel. ETX CPU Module Fig. 3-2 http://www.kontron.com... -
Page 12: Internal Jumper Setting
V Panel 104 / 121 / 150 / 170 / 190 User Manual Connector Interface Serial port COM3 Serial port COM4 Backlight interface Advanced power button interface External battery connector Internal Fieldbus interface Floppy disk drive interface Secondary IDE Compact flash... - Page 13 3.3.9 Function front power bottom Setting SW2 DIP3 Funktion Compact Flash Powerbutton J12 disabled ON (default) Powerbutton J12 enabled 3.3.10 Configuration USB Port 2 Setting SW2 DIP4 Funktion Compact Flash OFF (default) USB Port 2 enabled USB Port 2 disabled http://www.kontron.com...
-
Page 14: Led Status Indicators
V Panel 104 / 121 / 150 / 170 / 190 User Manual 3.3.11 Communication port to touchcontroller Setting SW3 DIP1 Communication port COM COM1 COM4 3.3.12 Touch wire configurationr Setting SW3 DIP2 Touchtype 5 wire 4 wire 3.3.13 Output configuration USB Port 0... -
Page 15: Software Installation
All the drivers are stored on the provided Support CD. Drivers also available at the online support at http://www.kontron.com. If you need additional help please contact Kontron customer service. 4.2.1 Install Touch driver Installed touch controllers Installed Touch 10,4”... - Page 16 V Panel 104 / 121 / 150 / 170 / 190 User Manual >>Start installation and set folder >>Choose your destination folder © Copyright Kontron Embedded Computers GmbH...
- Page 17 Tel: +49 9461 950 - 0 Fax: +49 9461 950 - 100 >>Choose display of touch icon in system tray >>Select installed touch controllers Value: 1 >>Select spread of touch on display Value line 1:“Whole Desktop” Value line 2:“Device1” http://www.kontron.com...
- Page 18 V Panel 104 / 121 / 150 / 170 / 190 User Manual >> Select controler type Value: DMC TSC-10 Series USB >> Installation Calibration To get the according touch function you had to calibrate the touch. To do this go to START/Programs/DMC/ Calibrate Do the calibration with a touch stick on the displayed arrows.
- Page 19 Werner-von-Siemens Str.1 D - 93426 Roding Tel: +49 9461 950 - 0 Fax: +49 9461 950 - 100 >> Choose your destination folder to extract files >> Select touch type “USB touchsreen “ http://www.kontron.com...
- Page 20 V Panel 104 / 121 / 150 / 170 / 190 User Manual >>Confirm licence agreement >>Start touch calibration © Copyright Kontron Embedded Computers GmbH...
- Page 21 To get access from your operating system to this controller you had to install the so called CIF device driver. You find this driver on the provided Hilscher system software CD in the folder DRIVER. Start installation with program SETUP.EXE at this folder. http://www.kontron.com...
- Page 22 V Panel 104 / 121 / 150 / 170 / 190 User Manual >>Select your destination folder >> Choose your program description © Copyright Kontron Embedded Computers GmbH...
-
Page 23: Technical Details
Verified OS Windows XP, Windows XP embedded, Linux Power Supply 24 VDC +/- 20% with protection against reverse polarity. Power consum. 62W I max 3,32 W Battery External Lithium 3,5V 750mAh MTBF < 40000 h (excluding backlight tube) http://www.kontron.com... -
Page 24: Environment
V Panel 104 / 121 / 150 / 170 / 190 User Manual 5.3 ENVIRONMENT Features V Panel all models Temperature Operating: 0° to +50°C Storage: -25° to +70°C Humidity Operation: 5 to 95% non condensino Storage: 5 to 95% non condensing... - Page 25 Blue CRTGND CRTGND CRTGND CRTGND CRTGND DDCDAT HSYNC VSYNC DDCCLK LAN2 Port Signal Name when 82541ER loaded 10/100/1000 Base T Signal name when 82551xx loaded 10/100 BaseT MX_0+ TXD+ MX_0- TXD- MX_1+ RXD+ MX_2+ MX_2- MX_1- RXD- MX_3+ MX_3- http://www.kontron.com...
- Page 26 V Panel 104 / 121 / 150 / 170 / 190 User Manual Power Connector Signal Name 24V IN RS232 Connector Signal Name DCD (Data Carrier Detect) RXD (Receive Data) TXD (Transmit Data) DTR (Data Terminal Ready) DSR (Data Set Ready)
- Page 27 FDDRVSB# (Drive Select B) FDDRVSA# (Drive Select A) FDMOTEB# (Motor Enable B) FDDIR# (Stepper Motor Direction) FDSTEP# (Step Pulse) FDWD# (Write Data) FDWG# (Write Enable) FDTRK0# (Track 0) FDWPD# (Write Protect) FDRD# (Read Data) FDSIDE# (Side 1 Select) DSKCHG# (Diskette Change) http://www.kontron.com...
- Page 28 V Panel 104 / 121 / 150 / 170 / 190 User Manual Secondary IDE Compact flash J17 Signal Name Signal Name Data 3 Data 11 Data 4 Data 12 Data 5 Data 13 Data 6 Data 14 Data 7...
- Page 29 B27 AD23 A58 AD00 B58 AD01 A28 AD22 B28 GND A59 +5V (I/O) B59 +5V (I/O) A29 AD20 B29 AD21 A60 NC B60 NC A30 GND B30 AD19 A61 +5V B61 +5V A31 AD18 B31 +3.3V A62 +5V B62 +5V http://www.kontron.com...
- Page 30 V Panel 104 / 121 / 150 / 170 / 190 User Manual PCMCIA connector J25 Signal Name Signal Name AD0_Data 3 AD1_Data 4 AD2_Data 11 AD3_Data 5 AD4_Data 12 AD5_Data 6 AD6_Data 13 AD7_Data 7 RSVD_Data 14 C/BE0#_CE1 AD8_Data 15...
-
Page 31: Options
Data- Data+ Data+ 5.6 OPTIONS 5.6.1 Operating Panel S1 is used to power on the system after standby. D1 indicates the status of power on. Signal Name LED- LED+ Powerbutton D1 LED Status Status Green Power on Orange Standby http://www.kontron.com... - Page 32 V Panel 104 / 121 / 150 / 170 / 190 User Manual 5.6.2 Fieldbus modules (optional) 5.6.2.1 Profibus module female Signal Name RXD-P/TXD-M ISODE ISOLATET GND ISOLLATED +5V RXD-M/TXD-M 5.6.2.2 Canbus module male Signal Name CANL ISOLATED GND CANH 5.6.2.3 DeviceNet module...
-
Page 33: Block Diagram
PCI-Riser 2nd LAN** PCMCIA** NVSRAM** Super I/O SJA1000* EC1* COM3 COM4 Fieldbus External interface COM3 Floppy PB, CAN Switchlogic DeviceNET Internal interface COM1 Touch COM4 * only SJA1000 or EC1 populated J29 und J30 ** optional populated fig. 5-1 http://www.kontron.com... -
Page 34: Maintenance
V Panel 104 / 121 / 150 / 170 / 190 User Manual 6. MAINTENANCE The Panel is designed and produced according to DIN EN ISO 9000:2000. One of the main development intentions was to minimice service requirements. As a result, with exception changing CMOS-Ram battery and cleaning, no great service is to do. -
Page 35: Packaging
For additional questions please contact the customer service by fax or Email. Fill out all the menu items on the form and send it to Kontron by FAX or online. Describe the error as detailed as possible. A detailed report is a base for a fast and effective analyze of errors and repair. -
Page 36: Troubleshooting
V Panel 104 / 121 / 150 / 170 / 190 User Manual 7. TROUBLESHOOTING 7.1 FAQ Please look to the online support at www.kontron.com 8. DISPOSAL In order to dispose your Panel, it must be removed from the plant and fully dismantled.
