RIGHT SIDE VIEW
12
13
14
15
(1) Rear master cylinder
(2) Brake pedal
(3) Kickstarter pedal
(4) Oil level dipstick
(5) Front brake caliper assembly
(6) Front disc
(7) Throttle body
(8) Seat
*Accessories and features shown may not be part of standard fitment.
11
10
9
8
1
7
2
3
4
(9) Tool kit compartment (inside)
(10) Fuse box (inside)
(11) USB charger & First aid kit
compartment (inside)
(12) Air cleaner assembly (inside)
(13) Rear brake caliper assembly
(14) Exhaust muffler
(15) Rear disc
6
5
6
