HERO XPULSE 200T PROGRAMMED FI Manual page 19

Description
Sl. No.
Programmed-FI
malfunction indicator
8
lamp (MIL)
9 Mode button
10 Set button
11 Next service distance
12 Fuel gauge
Service reminder
13
indicator
14
Odometer
Speedometer
15
Digital clock
16
17
Gear indicator
When the ignition switch is turned "ON" the programmed
FI malfunction indicator lamp (MIL) glows continuously
and then should go "OFF" once the engine is started. It
indicates that programmed FI system is OK. If it glows
continuously there is an abnormality in the programmed
FI system, it is recommended to reduce the speed and
drive to the Authorised
check-up.
Switches display between odometer, tripmeter-1 & 2,
clock, eco mode & bluetooth connectivity.
To adjust clock, date & tripmeter.
When long pressed resets tripmeter to zero.
Indicates how many kilometers are left before the
next service is due. It appears for few seconds when the
ignition switch is turned "ON" ( ) (page 20).
Indicates approximate fuel available in the form of
digital segments. The digital segments will swing to
maximum scale on the meter console once the ignition
switch is turned "ON" ( ) (page 20).
Displays when the next service is due (page 20).
Shows accumulated distance travelled (page 18).
Indicates riding speed
Indicates hours & minutes
Displays the selected gear while riding (page 22).
16
Function
Hero MotoCorp
.
(page 17)
.
workshop for
