▲Technical Specifications

\ MODEL: BT04/BT05
\ DIMENSION: 196× 208× 192mm
\ WEIGHT: 6.0kg
\ VOLTAGE: 220V(BT04)/110V(BT05), 50/60Hz
\ WORK POWER: 500W
\ EFFECT HEIGHT: 2-7m(according to HC8200 type)
\ INTERFACE:3-pin XLR, POWER IN/OUT
\ CONTROL: DMX 2 channels, Wireless Remote
\ ADAPTABLE TRUSS SIZE: 40-60mm

▲Operation Panel

1. LED display area:
READY DMX FAU LT HEAT
READY: After turning on machine, it will automatically preheat around 5 minutes, when the
"READY" green light turns from flashing into long on, indicates that the machine is ready to
work
DMX: Flashing shows that DMX signal is connected, otherwise is without signal
FAULT: When any malfunction , the light turns on
HEAT: When the machine is heating, signal light turns on
2. Control button area:
MENU short press to switch interface, press for 3 seconds can switch to the advanced setup
interface
-: Parameters down
+: Parameters up
ENTER Confirm and save parameters.
