3. Ordering information

Model CD3000S 2PH
CD3000S-2PH
Ex:CD3000S 2PH/ 150A/
1 Nominal CURRENT of CD3000S
125A 275A
150A 400A
200A 450A
2 Operating Load Voltage (incoming voltage supply)
Specify the value of the line supply.
3 Max VOLTAGE of CD3000S
480V
600V
The voltage on the identification label must be equal or more than
operating voltage. The minimum voltage supply to the load is 24V.
4 Auxiliary Voltage
230V 200÷230V ±15%; 10VA
460V 300÷460V ±15%; 10VA
600V 600V ±15%; 10VA (on request)
5 Input
SSR 4÷30VDC
6 Firing
ZC Zero Crossing
7 Options
FAN110 Fan voltage supply 110VAC ± 15% (std 230VAC ± 15%)
14W 50/60Hz
UL UL Certification
CD3000S-2PH from 125A to 700A
1 2 3
400V/ 480V/ 230V/
500A
600A
700A
4 5 6
SSR/ ZC/ UL
7
