Reference design
5 Reference design
5.1 Main
The reference design shown in
integrated microcontroller running at 72 MHz, that combines the new Cortex
RISC CPU core with 128 Kbytes of embedded Flash memory and up to 20 Kbytes of high
speed SRAM
5.1.1 Clock
Two clock sources are used for the microcontroller:
X1– 32.768 kHz crystal for the embedded RTC
X2– 8 MHz crystal for the STM32F10xxx microcontroller
Refer to
5.1.2 Reset
The reset signal in
Reset button (B1)
Debugging tools via the connector CN1
Refer to
5.1.3 Boot mode
The STM32F10xxx is able to boot from the:
embedded user Flash memory
embedded SRAM for debugging
system memory
The boot option is configured by setting switches SW2 (Boot 0) and SW1 (Boot 1). Refer to
Section 3: Boot configuration on page
5.2 SWJ interface
The STM32F10xxx core integrates the serial wire / JTAG debug port (SWJ-DP). The
reference design shows the connection between the STM32F10xxx and a standard JTAG
connector. Refer to
5.3 Power supply
Refer to
