Cable Recommendations - EKE-Electronics CVB1621A Technical Manual

The following table specifies the EMC test details of the CVB module.
Table A.11: EMC test specifications
Parameter
Conducted emission
Radiated emission
Fast transient burst
immunity
Surge immunity
Radiated RF field
immunity
Conducted RF common
mode immunity
Electrostatic discharge

Cable recommendations

Table A.12: Mating connector for CAN interface (X1 and X2)
Description Manufacturer
Connector ITT Cannon
Contact ITT Cannon
Housing FCT
CVB1621A and CVB 2456A Technical Manual, ver. 3.00
In Test conditions
conformance
with
EN 55011
< 99 dB
< 93 dB
EN 55011
< 40 dB
< 47 dB
EN 61000-4-4 ± 2 kV, 5/50 ns, 5 kHz
EN 61000-4-5 1.2/50 µs, 42 Ohm + 0.5 µF,
± 2 kV line-to-ground,
± 1 kV line-to-line
EN 61000-4-3 20V/m at 80–1000 MHz and
10V/m at 1.4–2.5 GHz
EN 61000-4-6 10 Vrms, AM, 1 kHz, unmodulated carrier,
80 % at 0.15–80 MHz
EN 61000-4-2 ± 6kV contact, ± 8kV air, which is applicable
Type
DEUH-9S-F0
030-1953-000
FMK1-M3
µ
V quasi-peak at 0.15–0.5 MHz,
µ
V quasi-peak at 0.5–30 MHz
µ
V/m quasi-peak at 30–230 MHz,10 m
µ
V/m quasi-peak at 230–1000 MHz,10 m
53
