Table 5.4: Addresses and contents for the physical address space
Address range in absolute
addressing mode
0x00000 - 0x0FFFF
0x10000 - 0x1FFFF
0xC0000 - 0xFFFFF
When you want to read or modify software version-specific data, use logical
addressing. The following table contains a memory map for the 16-bit logical address
space.
Table 5.5: Addresses and contents for the logical address space
Address range in logical
addressing mode
0x0000 - 0xAFFF
0xB000 - 0xCFFF
0xD000 - 0xFFFF
If you give the ADDR command with no parameter, it displays the current
addressing mode. All parameters must be entered in lower case.
EXAMPLE
dbg>addr a
sm and rm commands apply absolute addressing.
dbg>addr l
sm and rm commands apply logical addressing.
dbg>addr
sm and rm commands apply logical addressing.
CVB1621A and CVB2456A Technical Manual, ver. 3.00
Memory contents
Executable code image in
RAM. During reset, the
system reads this image
from on-board Flash
memory.
Data area in RAM.
Shared memory visible to
Zilog and to the VME master
CPU (through VME bus).
Memory contents
Non-banked executable code.
This program code is always
visible.
8 KB window for accessing the
shared memory of the module or
the banked executable code.
Firmware data area
Command line interface
Address in logical
addressing mode
0x0000
0xD000
0xB000-0xCFFF (through an
adjustable 8 KB window)
Address in absolute
addressing mode
Overlaps the corresponding
area in physical address
space.
Banked code overlaps the
following areas in the
physical address space:
0xB000 – 0xCFFF
0xD000 – 0xEFFF
0xF000 – 0xFFFF
Overlaps the area in physical
address space starting at
0x10000.
