Installing the CVB into a rack
When handling the module, only touch the front panel. Do not touch the
board or any of the components on it.
Do not drop the module.
Make sure that the module or any of the components on it do not get wet.
Even when you are removing a defective module and sending it to
maintenance, handle the module according to these instructions.

3.1.2 Preparations

Before you start installing the CVB module into a rack, make the following preparations.
Make sure you have a Pozidrive Pz0 or Pz1 screwdriver to tighten the screws on
the module.
Check the shipping container to see that it is not damaged.
Take the module out of its shipping container carefully. The module is always
shipped in an ESD protective wrapping.
Check the module, especially the connector on the back, for any visible signs of
damage that may have occurred during shipment.

3.2 Installation procedure

The following sections include instructions for installing the CVB module into a rack.

3.2.1 Placing the module in the rack

The first step in the CVB installation is placing it in the rack. Do the following:
1 Hold the module by the front plate.
2 Place the module on the rails of the rack.
3 Slide the module towards the back plane of the rack until it clicks into its place. Do
not use force.
4 Tighten the two screws on the front panel.
5 If there are other modules in the rack, make sure that the front plate of the CVB
module is at the same level with the other modules.
If the module does not fit into its place in the rack, see section 3.3 on page 14.
