Pin order and connector specifications

The following tables specify the connector details for the CVB module.
X1 - CAN channel A
Connector is standard 9 pin sub D-type, male.
Table A.2: Pin order, connector X1
Pin Signal
1 Not Connected
2 CAN_A_L
3 CAN_A_GND
4 Not Connected
5 CAN_A_SHLD
6 CAN_A_GND
7 CAN_A_H
8 Not Connected
9 Not Connected
X2 - CAN channel B
Connector is a standard 9 pin sub D-type, male.
Table A.3: Pin order, connector X2
Pin Signal
1 Not Connected
2 CAN_B_L
3 CAN_B_GND
4 Not Connected
5 CAN_B_SHLD
6 CAN_B_GND
7 CAN_B_H
8 Not Connected
9 Not Connected
48
Description
CAN Dominant Low bus line
CAN Ground
Optional CAN shield
Optional CAN Ground
CAN Dominant High bus line
Description
CAN Dominant Low bus line
CAN Ground
Optional CAN shield
Optional CAN Ground
CAN Dominant High bus line
