Compliance with standards

The following table specifies the compliance of the CVB module with standardized
tests.
Table A.9: Characteristic tests
Test
Visual inspection
Performance
Insulation
Isolation (voltage withstand)
Conformal coating

Environmental and EMC test specifications

The following table specifies the environmental details of the CVB module.
Table A.10: Environmental specifications
Parameter
Operating temperature
Cooling test
Dry heat test
Damp heat
Vibration
Shock
52
Reference
EN 50155
EN 50155
EN 50155,
EN 50155
Yes, acrylics, UL approved,
MIL-I-46058C
In conformance with
EN 50155 class TX
EN 50155:2007 12.2.3
EN 60068-2-1 Ad
EN 50155:2007 12.2.4
EN 60068-2-2 Bd
EN 50155:2007 12.2.5
HD 323.2.30 Db
EN 50155:2007 12.2.11
EN 50155:2007 12.2.11
EN 60068-2-27 Ea
CVB1621A and CVB 2456A Technical Manual, ver. 3.00
Test conditions
Ambient temperature
(25 °C ± 10°)
500 VDC
1 kVac at 50 Hz, 1 min.
Test conditions
–40... +70 º C
2 h at -40 °C, power off
6 h at +70 °C
10 min at +85 °C, power on
+55 °C/+25 °C, 2 cycles,
2x24 h
2
5...150 Hz, 7.9 m/s
2
50 m/s for 30 ms
