Assembling The Adjustable Net - MacDon C Series Operator's Manual
Corn header
Hide thumbs
Also See for C Series:
- Unloading and assembly instructions (17 pages) ,
- Operator's manual (70 pages) ,
- Unloading and assembly instructions (96 pages)
Table of Contents
Advertisement
Technical documentation for assembling the sunflower saver net
Using M8x25 bolts fasten the central net and the side net to the holder.
M8 nut
1.331.640
1.379.829
M8 x 25 bolt
9.3 Assembling the adjustable net
Using M8x20 bolts fasten the adjustable nets to the side net parts.
M8 x 20 bolt
M8 nut
42
