Appendix B. Bill of Materials

Table B.1. MachXO 2280 Breakout Board Bill of Materials

Item Quantity
1 2
2 38
3 2
4 1
5 2
6 8
7 1
8 1
9 1
10 8
11 1
12 3
13 1
14 18
15 5
16 1
17 2
18 1
19 8
20 4
21 101
22 10
23 1
24 1
25 1
26 1
27 1
