7.2.8. USB Programming and Debug Interface
The USB mini-B socket of the Breakout Board serves as the programming and debug interface.
JTAG Programming: For JTAG programming, a preprogrammed USB PHY peripheral controller is provided on the
Breakout Board to serve as the programming interface to the MachXO 2280 PLD. Programming requires the ispVM
System software.
Table 7.15. USB Interface Reference
Item
Reference Designators
Part Number
Manufacturer
Website
© 2011-2021 Lattice Semiconductor Corp. All Lattice trademarks, registered trademarks, patents, and disclaimers are as listed at www.latticesemi.com/legal.
All other brand or product names are trademarks or registered trademarks of their respective holders. The specifications and information herein are subject to change without notice.
FPGA-EB-02038-1.2
Description
U2
FT2232HL
Future Technology Devices International (FTDI)
www.ftdichip.com
MachXO 2280 Breakout Board Evaluation Kit
Evaluation Board User Guide
27
