Installation; Architectural Panels; Hooded Panels; Flush Panels - AES global Cellcom Prime 5AB Manual

Speech
Unit
4-5 feet
Entrance
minimum
Pillar
Loosen top 2 screws only
Call Button
Optional keypad
module
Call Button
Optional keypad
module
Tip: Use appropriate fixings to ensure the intercom cannot be removed from the wall.
P a g e | 4

Installation

Do not remove the protective film until the system is
fully installed and working. Protective coverings are
there to protect the intercom from scratches and
200mm
marks during installation.
min
Antenna height is best higher than intercom for
cleaner audio and also better reception.

Architectural Panels

Hooded Panels

Loosen top 2 screws only

Flush Panels

Remove
Hinge front door
Side View
Hinge front door
Side View
Side View
Flush with surface
