IN100
EK1 Exit Device
Retrofit Kit
Installation Instructions
A8277A
02/21
Copyright © 2021, Sargent Manufacturing Company, an ASSA ABLOY Group company.
All rights reserved. Reproduction in whole or in part without the express written permission
of Sargent Manufacturing Company is prohibited.

Advertisement

loading
Need help?

Need help?

Do you have a question about the IN100 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Sargent IN100

Summary of Contents for Sargent IN100

  • Page 1 EK1 Exit Device Retrofit Kit Installation Instructions A8277A 02/21 Copyright © 2021, Sargent Manufacturing Company, an ASSA ABLOY Group company. All rights reserved. Reproduction in whole or in part without the express written permission of Sargent Manufacturing Company is prohibited.

  • Page 2: Table Of Contents

    EK Exit Device Retrofit Kit for IN100 Table of Contents Warning ...................3 General Description ..............4 Hardware Specifications ............4 Electronic Specifications ............4 Installation Instructions ............5 Operational Check ..............18 1-800-810-WIRE • www.sargentlock.com • A8277A...

  • Page 3: Warning

    Pour plus d’informations, visitez: www.P65warnings.ca.gov. Any retrofit or other field modification to a fire rated opening can potentially impact the fire rating of the opening, and SARGENT Manufacturing makes no representations or warranties concerning what such impact may be in any specific situation. When retrofitting any portion of an existing fire rated opening, or specifying and installing a new fire-rated opening, please consult with a code specialist or local code official (Authority Having Jurisdiction) to ensure compliance with all applicable codes and ratings.

  • Page 4: General Description

    EK Exit Device Retrofit Kit for IN100 General Description The EK Exit Device Retrofit Kit is designed to link the SARGENT IN100 Series product line with non-SAR- GENT rim exit devices. The EK Retrofit Kit is designed specifically to link to the Von Duprin 98/99 Series ®...

  • Page 5: Installation Instructions

    EK Exit Device Retrofit Kit for IN100 Installation Instructions *For mechanical (dummy) trim installation, refer to Steps 4, 5, and 7 only. Major Component Assembly Breakdown Item Description EK Kit Existing Hardware Outside Escutcheon Assembly Outside Trim Assembly Replacement EK Retrofit...
  • Page 6 EK Exit Device Retrofit Kit for IN100 1 Remove All Von Duprin 98/99 Exit Hardware from Door ® See diagram and part description on page 4 showing existing assemblies to be removed. 2 Door Preparation Inside A. Verify Hand and Bevel of Door •...
  • Page 7 EK Exit Device Retrofit Kit for IN100 C. Install Door Position Switch (DPS) 1. Insert connector end of DPS through the raceway on the latch edge of the door (Fig. 2C). Note: For metal doors, use DPS Collar. 2. Push DPS firmly into place by hand.
  • Page 8 EK Exit Device Retrofit Kit for IN100 3 Von Duprin 98/99 Series Rim Exit Hardware Preparation ® Installing and Wiring the Request to Exit - RX Switch (not included) The RX kit must be installed in order for the product to operate as intended. The RX kit can be ordered from an authorized distributor.
  • Page 9 EK Exit Device Retrofit Kit for IN100 4 Installing the Cylinder 1. Remove existing rim cylinder from trim previously removed from door. 2. Measure the cylinder length (see Fig. 4B). 3. There are three (3) collars (see Table 4C below) provided to accommodate the various cylinder lengths.
  • Page 10 Attach gasket to the outside escutcheon (Fig. 5). Fig. 5 6 Installing the EK • The SARGENT EK Exit Device Retrofit Kit requires installation of the NL (Night Latch) Drive Screw (Fig. 6) and is included with the EK Exit Device Retrofit Kit. •...
  • Page 11 EK Exit Device Retrofit Kit for IN100 7 Mounting the EK Route wires and cables as shown in Fig. 7. Grounding Exit Trim Cable Cable Door Position Switch (DPS) Blue Fig. 7 Wire Nut Yellow Green 1. Connect Exit Device Retrofit Kit (EK) Blue wire to NO (normally open) wire of RX chassis wire.
  • Page 12 EK Exit Device Retrofit Kit for IN100 8 Mount the Outside Reader 1. Orient the reader so the LED lens is at the top. 2. Feed the cable/connector through the door (from outside to inside). 3. Install the reader to the outside of door by aligning the mounting posts with the door preparation holes.
  • Page 13 EK Exit Device Retrofit Kit for IN100 10 Install Outside Reader and Mounting Plate Assembly 1. Route cables/connectors through the inside mounting assembly (and gasket if required*). 2. Insert and partially tighten (2) through-bolts prior to installation of connectors. Note: Cable lengths exaggerated for illustrative purposes.
  • Page 14 EK Exit Device Retrofit Kit for IN100 11 Installation of Connectors 1. Secure the following connectors to their respective terminals (Figure 10A): *Optional 12-24VDC Power CAUTION: Do not touch or allow debris to enter connector contacts. Remote Power Harness Wire Terminations •...
  • Page 15 EK Exit Device Retrofit Kit for IN100 12 Installing the Controller Install inside component assembly (controller). a. Insert bottom tab of controller (make sure path is clear) into Controller slot on mounting plate. (Figure 11A) b. Ensure proper alignment of board-to-board connectors while pivoting controller toward door until two tabs on top snap securely into place on mounting plate.
  • Page 16 EK Exit Device Retrofit Kit for IN100 13 Inside Cover Installation Install inside cover. (Figure 12) 1. Assemble cover by hooking top edge on inside mounting plate. 2. Carefully press bottom of cover toward door without pinching or damaging wires.

  • Page 17: Operational Check

    EK Exit Device Retrofit Kit for IN100 Operational Check IMPORTANT : Be sure to test functions prior to closing door. In all cases, perform the following checks: 1. Ensure that inside exit bar retracts latch. • To test cylinder, the following checks apply: Insert key into cylinder and rotate: a.
  • Page 18 EK Exit Device Retrofit Kit for IN100 Communication Hub LED Indications Communication hub has a single LED. It supports an optical scheme of red, green and yellow. Indication scheme is described by figures below: Communication Hub NORMAL OPERATION LED indication 2 sec.
  • Page 19 EK Exit Device Retrofit Kit for IN100 Lock LED Indications Lock has three (3) LEDs. They support an optical scheme with red, yellow and green. Indication scheme described by figures below: Lock NORMAL OPERATION LED indication EAC response Enter PIN...
  • Page 20 EK Exit Device Retrofit Kit for IN100 Lock Self-Test LED Indications After replacing batteries, a Power on Self Test (POST) is performed. The result is indicated using a series of red and green LED flashes as described by figures below:...
  • Page 21 EK Exit Device Retrofit Kit for IN100 Lock Busy LED Indications Lock BUSY indicates lock is processing a card (such as a key configuration card for online SE processor or offline void list card with many entries). Card should be kept in close proximity to reader until end of process. Lock BUSY indication does not cancel or overwrite any other indications.
  • Page 22 EK Exit Device Retrofit Kit for IN100 1-800-810-WIRE • www.sargentlock.com • A8277A...
  • Page 23 EK Exit Device Retrofit Kit for IN100 1-800-810-WIRE • www.sargentlock.com • A8277A...
  • Page 24 Copyright © 2021, Sargent Manufacturing Company, an ASSA ABLOY Group company. All rights reserved. Reproduction in whole or in part without the express written permission of Sargent Manufacturing Company is prohibited. HID and iCLASS are registered trademarks of HID Global Corporation. Von Duprin is a registered trademark of Von Duprin LLC.
