Lockly SECURE PRO Installation Manual page 7

Step 2
Determine right swing or left swing door
While facing the door from the inside, if hinges are on the right side you have the right swinging
door. If hinges on the left side you have a left swinging door.
The lock ships set for right swing doors. Skip STEP 2 if your door is a right swing door.
See steps below to change door handle orientation for a left swing door.
Changing the Exterior Handle Orientation
1
(Right handle)
Insert key and rotate lock
face so that the two white
dots align as shown.
CHANGING HANDLE FOR RIGHT OR LEFT SWING DOORS
2
R
Use the provided pin insert
to push the metal pin located
at the 3 o'clock of the the base
handle, then the other pin at 9
o'clock position. Remove the
handle once the pins are
compressed.
6
R
Rotate the handle 180
other side of the lock.
Using your fingers, press the
two pins located on the left
and right side of the the lock
to insert the handle back onto
the lock.
3
o
to the
