Step 6
continued
1
The interior assembly comes with the
pre-installed wired door sensor setup for
a right swing doors with 2 ¾" (70mm)
backset*.
Trim excess part (e) for doors with 2 ⅜"
(60mm) backset as shown below.
*Backset - measure the distance of the door edge to the center of the door hole.
PREPARING DOOR SENSORS FOR INSTALLATION
2
For left swing doors, re-route the door
sensor wire through the side channel.
Trim excess part (e) for doors with 2 ⅜"
(60mm) backset as shown below.
(AA)
e
Trim excess here for
2 ⅜" (60mm) backset*.
DO NOT INSTALL THE SENSORS YET
