Important Notice - Lockly SECURE PRO Installation Manual

Preparation
Remove existing door hardware, latch or deadbolts before installing the new lock.
Use provided template to bore new holes if needed.
1-3/8" ~ 2"
(35mm ~ 50mm)
1"
25mm

IMPORTANT NOTICE

* You are not required to drill an extra hole on your door. We have provided double sided
Adhesive tape for you to help stabilize the lock during installation. Only drill a hole if you
wish to have added stability. Please refer to the provided template for drilling if needed.
Use goggles to protect eyes if you need to drill door holes.
*
2-1/8"
54mm
*Optional
Backset
2-3/8" (60mm)
or 2-3/4" (70mm)
1
Measure and confirm your door is
between 1-3/8" ~ 2" ( 35mm - 50mm).
2
Measure and confirm the hole in the
door is 2-1/8" (54mm) .
3
Measure and confirm that the backset
is between 2-3/8" (60mm) to 2-3/4" (70mm).
4
Measure and confirm that hole in the
door edge is 1" (25mm).
4
