www.ti.com
8.2 Board Layout
Figure 8-1
shows the PCB layout for the ADS8688EVM.
The board layouts is not to scale. This figure is intended to show how the board is laid out and is not
intended to be used for manufacturing ADS8688EVM PCBs.
SBAU230C – AUGUST 2014 – REVISED MARCH 2021
Submit Document Feedback
Top
Botom
Figure 8-1. ADS8688EVM PCB
Copyright © 2021 Texas Instruments Incorporated
Note
Bill of Materials, Schematics, and Layout
ADS8688EVM-PDK Evaluation Module
19
