EVM Operation

7.2 Modifying Hardware and Using Software to Evaluate Other Devices in the Family

The ADS8688 is part of a family of related devices. This EVM hardware and software support the entire family
because all the devices are pin-for-pin compatable.
following procedure shows how to modify the hardware and software to evaluate the other devices in this family.
1. Desolder the ADS8688 and replace this device with the device you want to evaluate.
2. Enable the EEPROM for writing. This process is done by changing switch S2 to the top position using
tweezers.Figure 7-3 details this process.
3. Connect the EVM and start the GUI as described in
4. Use the Tools menu to Load EEPROM according to the device that is currently installed. When this
procedure is successfully completed, you will see the status bar at the top of the software update according
to the device installed on the hardware. For details, see
Resolution
Number of Channels
12-Bit
4 ADS8664
8 ADS8668
3. (š Œ ‰Œ ••]vP ^o}
take a few minutes to load the
EEPROM.
Figure 7-4. Configure EEPROM and Software for the New Device
12 ADS8688EVM-PDK Evaluation Module
Table 7-1
Section

Table 7-1. Compatible Devices in the Family

14-Bit 16-Bit
ADS8674 ADS8684
ADS8678 ADS8688
Use tweezers to change position of
switch S1 up as shown to allow the
EEPROM write operation.

Figure 7-3. Enable EEPROM for Writing

1. Kv šZ ^š}}o•_ u vµ • o š
^>} WZKD_
WZKD_ ]š Á]oo
4. The top of the status bar on the software
will indicate what the EVM connected has
been updated to.
Copyright © 2021 Texas Instruments Incorporated
lists other compatible devices in the family. The
7.1.
Figure 7-4.
ADS8684A
ADS8688A
2. hv Œ ^^µ‰‰}Œš À] •_ • o š
šZ •]Œ À] • v ‰Œ •• ^>}
WZKD_.
SBAU230C – AUGUST 2014 – REVISED MARCH 2021
www.ti.com
18-Bit
ADS8694
ADS8698
