Note
Some of the features mentioned above are optional (assembly option).
2.2

Supported Operating Systems

The conga-TCA5 supports the following operating systems
• Microsoft Windows
®
• Microsoft ® Windows
• Linux 3.x/4.x
• Yocto 2.x
Note
Windows ® 10 installation requires a minimum storage capacity of 20 GB. We will not offer installation support for systems with less than 20 GB
storage space.
2.3

Mechanical Dimensions

• 95.0 mm x 95.0 mm (3.75" x 3.75")
• Height approximately 18 or 21 mm (including heatspreader) depending on the carrier board connector that is used. If the 5 mm (height)
carrier board connector is used then approximate overall height is 18 mm. If the 8 mm (height) carrier board connector is used then
approximate overall height is 21 mm
Copyright © 2017 congatec GmbH
10 Enterprise (64-bit)
®
® 10 IoT Core (32/64-bit)
4.00
7.00
5.00
1.60
4.50
Heatspreader
Module PCB
Carrier Board PCB
TA50m19
13.00
18.00
16/70
