The table below shows the conga-TCA5 display combinations. This table does not apply to customized variants equipped with optional VGA
interface.
Table 9 Display Combination
Display 1 Display 2
(DDI0) (DDI1)
TMDS TMDS
DP DP
TMDS DP
5.1.2.1

DisplayPort (DP)

The conga-TCA5 supports the following:
• up to two DP ports
• VESA DisplayPort Standard 1.2
• up to 4096x2160 at 60 Hz
• maximum of two independent DP displays
5.1.2.2

LVDS

The conga-TCA5 offers an LVDS interface with optional eDP overlay on the A-B connector. The LVDS interface provides LVDS signals by default,
but can optionally support eDP signals (assembly option). For more information, contact congatec technical center.
The LVDS interface supports:
• single or dual channel LVDS (color depths of 18 bpp or 24 bpp)
• integrated flat panel interface with clock frequency up to 112 MHz
• VESA and OpenLDI LVDS color mappings
• automatic panel detection via Embedded Panel Interface based on VESA EDID
• resolution up to 1920x1200 in dual LVDS bus mode
Note
The LVDS/eDP interface supports either LVDS or eDP signals. Both signals are not supported simultaneously.
Copyright © 2017 congatec GmbH
Display 3 Display 1
Max. Resolution
eDP 3840 x 2160 @ 30 Hz, 24 bpp
eDP 4096 x 2160 @ 60 Hz, 24bpp
eDP 3840 x 2160 @ 30 Hz, 24 bpp
Display 2 Display 3
Max. Resolution Max. Resolution
3840 x 2160 @ 30 Hz, 24 bpp 4096 x 2160 @ 60 Hz, 24 bpp
4096 x 2160 @ 60 Hz, 24bpp 4096 x 2160 @ 60 Hz, 24 bpp
4096 x 2160 @ 60 Hz, 24bpp 4096 x 2160 @ 60 Hz, 24 bpp
