Revision History
Revision Date (yyyy-mm-dd) Author
0.1 2017-03-23
1.0 2017-10-04
1.1 2018-03-19
1.2 2018-06-25
1.3 2018-08-21
1.4 2019-07-25
1.5 2020-04-15
1.6 2020-12-08
1.7 2021-04-19
Copyright © 2017 congatec GmbH
Changes
•
AEM Preliminary release
AEM • Removed Android from supported OS in section 2.2 "Supported Operating Systems"
•
Updated security features in table 1 "Feature Summary" and section 6.5 "Security Features"
• Updated tables 5 "Power Consumption Values" and 6 "CMOS Battery Power Consumption"
• Updated section 4 "Block Diagram"
•
Added content to sections 9 "System Resources", 10 "BIOS Description" and 11 "Additional BIOS Features"
•
Official release
AEM • Updated "Electrostatic Sensitive Device" information on page 3
•
Removed Windows 7, 8 and Embedded Compact from the list of supported OS in section 2.2 "Supported Operating
Systems"
• Updated section 4 "Block Diagram"
•
Added caution in section 5.1.4 "USB 2.0"
• Updated section 5.1.8 "UART"
•
BEU Added errata as a document to read in the preface section
AEM • Deleted all notes with references to section 8.5 "Boot Strap Signals"
• Deleted product variant with PN: 048513 from table 3 "Industrial Variants"
AEM
• Updated section 4 "Cooling Solutions" and added table 7 "Cooling Solution Variants"
• Changed the recommended maximum torque specification for all cooling screws in section 4 "Cooling Solutions"
•
Updated the supported Winbond flash in section 10.4 "Supported Flash Devices"
AEM • Updated section 10.4 "Supported Flash Devices"
•
Added note about the minimum pulse width required for proper button detection in table 24 "Power and System
Management Signal Descriptions"
• Corrected sections 5.2.1 "USB 3.0" and 7.3 "USB Port Mapping"
•
Updated section 6.1.1 "Optional eMMC 5.0"
• Deleted section 11 "References"
• Restructured the whole document
•
AEM Corrected a typographical error in section 10.4 "Supported Flash Devices"
• Corrected the temperature range of industrial variants in section 2.7 "Environmental Specifications"
• Updated section 6.1.1 "Optional eMMC 5.0"
•
Updated the note in section 5.1.9 "UART"
AEM • Corrected the storage temperature for industrial variants in section 2.7 "Environmental Specifications"
•
Updated table 2 "Commercial Variants, table 3"Industrial Variants", table 4 "Feature Summary", table 9 "Display
Combination" and table 17 "TMDS Signal Descriptions"
• Updated section 3 "Block Diagram" and section 5.1.2 "Display Interfaces
• Deleted section 5.1.2.1 "HDMI" and section 5.1.2.2 "DVI"
• Added note to table 17 "TMDS Signal Descriptions"
