Cascade UTF2-08-1004-1885315 Use And Maintenance Manual page 30

N° Q.ty
1 1
2 1
3 1
4 1*
5 1*
6 1*
7 1
8 1
9 1*
10 1*
-
11
12 1*
13 1*
14 1*
*SEAL KIT 6527400
Cascade Italia supply only complete Seal kit.
Cylinder 6566052
(S-48972)
Description
Shell weldment
Rod
Spacer tube
O ring 70 duro
Rod seal
Piston wear ring
Piston
Retainer
Rod wiper
O ring
N/A
O ring 70 duro
Backup ring
Piston seal
P/N
6566053
6566054
-
643373
6521345
-
6402629
6402610
6521341
6406906
-
6406652
6402648
6402628
