USER MANUAL
OPERATION AND PERIODIC MAINTENANCE
Weigh Forks
Walkie
CAUTION: This is a precise weighing
system, treat with care. Environment and
application will affect the system and
its components. Conditions with mud,
grime, water, corrosive chemicals and
abrasive substances can damage or effect
performance of the Walkie Weigh Forks.
Manual Number 6917949

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Walkie and is the answer not in the manual?

Questions and answers

Related Manuals for Cascade Walkie

Summary of Contents for Cascade Walkie

  • Page 1 CAUTION: This is a precise weighing system, treat with care. Environment and application will affect the system and its components. Conditions with mud, grime, water, corrosive chemicals and abrasive substances can damage or effect performance of the Walkie Weigh Forks. Manual Number 6917949...

  • Page 2: Table Of Contents

    CONTENTS Page OVERVIEW WARNINGS & SAFETY MEASURES USING DISPLAY Functions Display Messages USING WALKIE WEIGH FORKS Prior To Weighing Handling Loads To Weigh A Load (Normal Weighing Mode) Obtaining Net/Tare/Gross Weight ADVANCED WEIGHING OPERATION Totaling (Accumulation) Piece Count (Sampling Method)

  • Page 3: Overview

    OVERVIEW This manual describes the use and operation of the Walkie Weigh Forks. Read this manual thoroughly prior to operation. Be sure to know and understand all operating procedures and safety operations. Perform operations in the order shown in this manual.

  • Page 4: Warnings & Safety Measures

    WARNINGS & SAFETY MEASURES When using Walkie Weigh Forks, carefully read the IMPORTANT: Field alterations may impair performance guidelines contained in this manual. If any of the or capability and could result in loss of warranty. Consult instructions are not clear, please contact your supervisor.

  • Page 5: Using Display

    USING DISPLAY Functions Right of Display Left of Display When the following appears: When the following appears: Quantity displayed is the number of Low Battery (if equipped) items on the scale The scale is zeroed Weight shown is in pounds The display is in PEAK HOLD mode Weight shown is in ounces The display is showing tare weight...

  • Page 6: Display Messages

    USING DISPLAY Display Messages Error Message Meaning To Exit Error Mode Forks are overloaded Automatic after removing weight Weight on scale is negative or load cell Press the ZERO/OFF key. signal is negative Lift the forks from the ground. Verify weigh system is powered ON. Problem with Fork 1, no communication Restart display.

  • Page 7: Using Walkie Weigh Forks

    USING WALKIE WEIGH FORKS Prior To Weighing Verify the display shows zero. If necessary, press the Zero button. Verify Weigh Forks are free of obstacles prior to zeroing Optimal Temperature Range: 15° F (-10° C) minimum 105° F (40° C) maximum FK0706.eps...

  • Page 8: To Weigh A Load (Normal Weighing Mode)

    USING WALKIE WEIGH FORKS To Weigh A Load (Normal Weighing Mode) IMPORTANT: • At initial daily start up, allow 3-5 minutes for the forks to warm up before weighing loads. • The system will not weigh correctly if the front face or bottom of the forks touches the load or pallet.

  • Page 9: Obtaining Net/Tare/Gross Weight

    USING WALKIE WEIGH FORKS Obtaining Net/Tare/Gross Weight FK0471.eps Net (A) + Tare (B) = Gross (C) Net – The weight of the load being weighed. Tare – The weight of an unladen load that is not included (pallet, bin, etc).
  • Page 10 USING WALKIE WEIGH FORKS Obtaining Net/Tare/Gross Weight (Continued) Add a load to weigh onto the forks. Load FK0703.eps The display will show the Net weight (only the load's weight). "N" disappears and "G" appears Gross Weight To view the Gross weight (Tare weight + Net weight), press the "NET/GROSS"...

  • Page 11: Advanced Weighing Operation

    ADVANCED WEIGHING OPERATIONS Totaling (Accumulation) This mode adds and totals a group of weights. Verify that the "F 30" parameter setting is "1". Refer to the Appendix section to verify and/or change the parameter setting. If required, change parameter setting "F 30" to "1". Refer to the Appendix section.
  • Page 12 ADVANCED WEIGHING OPERATIONS Totaling (Accumulation) (Continued) Press the "ON/PRINT" button to add the weighed load to the total. The display will show "AddEd". NOTE: If a printer is installed, the print out will show the Gross, Net and Tare weights. Repeat Steps 7-10 until all loads to be weighed, have been added.

  • Page 13: Piece Count (Sampling Method)

    ADVANCED WEIGHING OPERATIONS Piece Count (Sampling Method) This mode uses the sampling method to determine the average piece weight (APW) of a load that requires counting. First, a sample is taken and then the load is measured. Verify that the "F 30" parameter setting is "3". Refer to the Appendix section to verify and/or change the parameter setting.

  • Page 14: Auto Shut-Off

    AUTO SHUT-OFF After 5 minutes (default) of no action: On the display, a countdown screen shows. Press any button to cancel auto shut-off and return to normal weighing mode. After 20 seconds of no further action, "off" will appear on the screen.

  • Page 15: Printer Equipped

    PRINTER EQUIPPED Print Weight (Normal Weighing Mode) If required, zero the display. Position load on forks and raise forks. Load Weigh the load. FK0698.eps Press the "ON/PRINT" button to print. ID. No. 123456 Printer will print out load weight. GROSS 255.0 lb. TARE 50 lb.

  • Page 16: Periodic Maintenance

    PERIODIC MAINTENANCE IMPORTANT: Only trained and authorized personnel are allowed to service Weigh Forks. Other maintenance procedures are the sole responsibility of the purchaser. IMPORTANT: To prevent weighing inaccuracies, the end user is responsible to check accuracy on a regular basis at intervals that best fit their application and requirements.

  • Page 17: Appendix

    APPENDIX Enable/Change/Disable An Advanced Weighing Option To enable/change/disable an advanced weighing option (Parameter "F 30") perform the following procedure: With the display powered off, press and hold the "ON/ PRINT" button for approximately 20 seconds. 20 Seconds The display will show "-F-". Press the "ZERO/OFF" button.
  • Page 18 12-2018 Part Number 6917949...
