TVLogic F-5A Operation Manual page 16

5. Menu Operations
[3] MARKER
MARKER같이
ENABLE
MARKER
CENTER MARKER
SAFETY AREA
FIT MARKER
MARKER MAT
MARKER COLOR
THICKNESS
USER MARKER H1
USER MARKER H2
USER MARKER V1
USER MARKER V2
GRID ENABLE
GRID TYPE
GRID THICKNESS
GRID THROUGHOUT
• USER MARKER H1
- Used to set the position of the first horizontal
marker line.
- Displayed when the MARKER menu is set to
USER.
• USER MARKER H2
- Used to set the position of the second
horizontal marker line.
- Displayed when the MARKER menu is set to
USER.
• USER MARKER V1
- Used to set the position of the first vertical
marker line.
- Displayed when the MARKER menu is set to
USER.
• USER MARKER V2
- Used to set the position of the second vertical
marker line.
- Displayed when the MARKER menu is set to
USER.
F-5A
ON
OFF
OFF
OFF
OFF
OFF
WHITE
2
+
+1920
+
+1080
OFF
OFF
2
OFF
• GRID ENABLE
- Used to activate the GRID display function.
• GRID TYPE
- Used to select the GRID type.
- Available GRID types are 3x3, 4x4, 5x5 and 6x6.
• GRID THICKNESS
- Used to set the thickness of the GRID.
0
- Thickness level is from 1 to 5.
0
• GRID THROUGOUT
- Apply the currently applied GRID to
ThroughOut.
