TVLogic F-5A Operation Manual page 33

7. Other Functions
[9] HDMI To SDI Conversion-Out
• Video source from 'HDMI input' terminal
can be output through 'SDI throughout'
terminal.
Note: HDSLR camera manufacturers usually
specify the resolution and frame rate for the
recording. The signal format that is output
through HDMI terminal of cameras may differ
from makers to makers. The signal format for
HDMI output and playback function of Canon
HDSLRs is 59.94i. And even though 60i or 60p
is specified in the specification of the cameras,
the actual recording or HDMI output format
would be 59.94i or 59.94p.
Output
Format
Input
Format
480i(NTSC)
576i(PAL)
480P
576P
720P50
720P59.94
720P60
1080i50
1080i59.94
1080i60
1080p24
1080p25
1080p30
1080psF24
1080p50
1080p59.94
1080p60
1080p50 1080p60
●
●
●
●
●
●
●
●
●
●
●
●
●
●
●
●
●
[10] SDI To HDMI Conversion-Out
3G/HD/SD SDI signals from 'SDI input'
●
terminal can be output through 'HDMI
out' terminal.
Output
Format
Input
Format
480i(NTSC)
576i(PAL)
720P50
720P59.94
720P60
1080i50
1080i59.94
1080i60
1080p24
1080p25
1080p30
1080psF24
1080p50
1080p59.94
1080p60
1080p50 1080p60
●
●
●
●
●
●
●
●
●
●
●
●
●
●
●
