TVLogic F-5A Operation Manual page 23

5. Menu Operations
[5] WAVEFORM
WAVEFORM
ENABLE
TYPE
INTENSITY
TRANS
SIZE
LINE WAVEOFORM
SEL LINE POS
LUMA CHECK
LUMA ADJUST
RANGE ERROR
Y MAX
Y MIN
C MAX
C MIN
Y PICTURE BLINK
C PICTURE BLINK
• Y MAX
- Used to set the maximum Luma(Y') level from
0 to 255.
- Pixels with values exceeding the max Y' level
will blink on the screen, and be displayed in
red on the Waveform.
Y MIN
•
- Used to set the minimum Luma(Y') level from
0 to 255.
- Pixels with values exceeding the max Y' level
will blink on the screen, and be displayed in
red on the Waveform.
C MAX
•
- Used to set the maximum chroma(C') level
from 0 to 255.
- Pixels with values exceeding the max Y' level
will blink on the screen, and be displayed in
red on the Waveform.
C MIN
•
- Used to set the minimum chroma(C') level
from 0 to 255.
- Pixels with values exceeding the max Y' level
will blink on the screen, and be displayed in
red on the Waveform.
F-5A
OFF
OFF
+ 90
OPAQUE
SAMLL
OFF
+ 90
OFF
+ 90
OFF
+ 90
+ 90
+ 90
+ 90
OFF
OFF
Y PICTURE BLINK
•
- Used to set whether or not to blink pixels with
values exceeding Y MAX and Y MIN.
C PICTURE BLINK
•
- Used to set whether or not to blink pixels with
values exceeding C MAX and C MIN.
