I
NTRODUCTION
MTH410 is a professional radio microphone especially designed for broadcast/high quality
applications.
MTH410 is composed by 3 detachable parts:
•
MIC Head (available with cardioid/hyper-cardioid polar pattern).
•
MIC Body (the below part can be open to access "Display & Setup controls" area (fig.1) and on
the back the "Batteries holder & Infrared" area (fig. 2).
•
MIC Antenna, made with fibreglass reinforced housing and with a "Wireless power switch" (fig.
3). "MIC Antenna" is fastened to body with 2 anvils and a micro-connector.
1
Exchange head:
unscrew it counter-clockwise
Fig. 1 Display & Setup controls
2
1
Wireless power switch with
Fig. 2 Batteries holder and infrared
MTH410 User Manual
Open MIC Body:
Unscrew & slide down cover,
To access internal setup controls and
batteries holder & infrared.
3
1
programmable LED
indication (green/red).
Fig. 3 Wireless
power switch
3
