The following table sums up which parameters can be set and the related range settings.
MENU PARAMETER
CH
GR
TUNING
Freq
AF Gain
AF Level
Phase
HP
AUDIO
Noise R.
MOD
LP Filter
RF Power
RF/BATTERY
Battery
Led Light
Led Mode
LED
PTT Mode
MIC
MEANING RANGE SETTINGS
Channel 0 ÷ 59
Group 0 ÷ 39 + SYNC GROUP
Frequency It depends on the MTH410 Model:
See technical spec. and variants for further
details
Gain of the -40dB ÷ +40dB step of 1dB
audio signal -54dBu ÷ +26dBu step of 1dBu
Audio signal 0° or 180°
phase
High Pass filter Flat/60/80/120/170/250/400 Hz
Noise reduction ENR: Wisycom Extended-NR, noise optimized
ENC: Wisycom Extended-NC, voice optimized
Modulation WB wideband / NB narrowband
Audio Low Pass 12/15/20kHz
Filter
RF Power 10mW or 20mW or 50mW or 100mW
(depending on the power profile)
Battery type Alkaline, NiMH or Lithium
Power switch 0 ÷ 16
green
brightness
It defines when None: never
the power ModPeak: when audio get close to saturation
switch led (see PTT: when the PTT button is pushed
Fig. 3) has to
become RED
It defines how Disable: when the PTT button is pushed, nothing
and what happen. (the transmitter sends AF+Tone
information the squelch)
transmitter has Normal: when the PTT button is pushed, the
to send transmitter send a different RF signal. According
to the receiver configuration the audio can be
enabled/disable on LINE (and/or COM).
Muting: the transmitter doesn't send the audio.
The voice is cut, it doesn't enter to the
microphone
No Data: the transmitter sends neither tone
squelch nor battery data.
