10.1.8
Certificates and approvals
The measuring system meets the legal requirements of the applicable EC guidelines. These are listed
in the corresponding EC Declaration of Conformity together with the standards applied.
Endress+Hauser confirms successful testing of the device by affixing to it the CE mark.
Permitted pressures, temperatures and load cycles as per EN 13445 and AD- data sheet S2
(for FMP45).
Correlation of safety instructions (XA) and certificates (ZE) to the instrument:
Feature
Non-hazardous area
NEPSI Ex em(ia) IIC T6
Non-hazardous area, WHG
ATEX II 3G Ex nA II T6
NEPSI Ex ia IIC T6
NEPSI Ex d(ia) IIC T6
TIIS Ex d (ia) IIC T1
TIIS Ex d (ia) IIC T2
FM DIP Cl.II Div.1 Gr.E-G N.I.
CSA General Purpose
CSA DIP Cl.II Div.1 Gr.G +
*NEPSI DIP
10
NEPSI Ex nA II T6
Approval:
FM IS Cl.I,II,III Div.1 Gr.A-G N.I.
FM XP Cl.I,II,III Div.1 Gr.A-G
CSA IS Cl.I,II,III Div.1 Gr.A-D,G+
CSA XP Cl.I,II,III Div.1 Gr.A-D,G+
ATEX II 1/2G Ex ia IIC T6/IECEx Zone0/1
ATEX II 1/2D, Alu blind cover 1)
ATEX II 1/2G Ex emb (ia) IIC T6/IECEx
1)
ATEX II 1/3D
ATEX II 1/2G Ex ia IIC T6, ATEX II 1/3D
ATEX II 1/2G Ex ia IIC T6, WHG
ATEX II 1/2G Ex d (ia) IIC T6
ATEX II 1/2G Ex ia IIC T6
2-wire 4-20mA SIL HART
2-wire PROFIBUS PA
50
2-wire FOUNDATION Fieldbus
Power supply
4-wire 90-250VAC 4-20mA SIL HART
Output:
4-wire 10.5-32VDC 4-20mA SIL HART
2-wire 4-20mA HART, Interface
F12 Alu, coated IP68 NEMA6P
F23 316L IP68 NEMA6P
80
Housing:
T12 Alu, coated IP68 NEMA6P,
T12 Alu, coated IP68 NEMA6P + OVP
Verschr. M20 (EEx d > thread M20)
thread G1/2
90
thread NPT1/2
Cable entry:
Plug M12
Plug 7/8"
1) Housing F12/F23/T12-OVP: In combination with electronics B, D or F supply intrinsically safe.
