Technical data
Tolerance of probe length
Weight
Levelflex M
Rod probe
Weight with F12 or approx. 8.5 kg
T12 housing
approx. 1.6 kg/m
Probe length
Flange weight
Weight with F23 approx. 12 kg
housing
approx. 1.6 kg/m
Probe length
Flange weight
Material
98
10.1.7 Mechanical construction
over
up to
admissible tolerance (mm / inch)
over
up to
admissible tolerance (mm / inch)
XT version (max. 280 °C)
Rope probe
approx. 8.5 kg
+ +
approx. 0.1 kg/m
Probe length
+ +
Flange weight
approx. 12 kg
+ +
approx. 0.1 kg/m
Probe length
+ +
Flange weight
• Housing:
– housing F12/T12: aluminium (AlSi10Mg), seawater-resistant, powder-coated
– housing F23: 316L, corrosion-resistant steel
• Sight window: glass
Levelflex M FMP45 with FOUNDATION Fieldbus
Rod probes
1 m / 3.2 ft
- 5 / - 0.2
Rope probes
1 m / 3.2 ft
- 10 / - 0.4
FMP45
Coax probe Rod probe
approx. 8.5 kg approx. 9.5 kg
+ +
approx. 3.5 kg/m approx. 1.6 kg/m
Probe length Probe length
+ +
Flange weight Flange weight
approx. 12 kg approx. 13 kg
+ +
approx. 3.5 kg/m approx. 1.6 kg/m
Probe length Probe length
+ +
Flange weight Flange weight
1 m / 3.2 ft 3 m / 9.8 ft
3 m / 9.8 ft 6 m / 20 ft
- 10 / - 0.4 - 20 / - 0.8
1 m / 3.2 ft 3 m / 9.8 ft
3 m / 9.8 ft 6 m / 20 ft
- 20 / - 0.8 - 30 / - 1.2
HT version (max. 400 °C)
Rope probe
approx. 9.5 kg
+
approx. 0.1 kg/m
Probe length
+
Flange weight
approx. 13 kg
+
approx. 0.1 kg/m
Probe length
+
Flange weight
6 m / 20 ft
- 30 / - 1.2
6 m / 20 ft
- 40 / - 1.6
Coax probe
approx. 9.5 kg
+
approx. 3.5 kg/m
Probe length
+
Flange weight
approx. 13 kg
+
approx. 3.5 kg/m
Probe length
+
Flange weight
