87030 Revision Date 5.14.21
Residential Condensing Gas Boiler
Heat Exchanger Bears the ASME "H" Stamp
DANGER
THIS MANUAL MUST ONLY BE USED BY A QUALIFIED INSTALLER / SERVICE
TECHNICIAN. READ ALL INSTRUCTIONS IN THIS MANUAL BEFORE
INSTALLING. PERFORM STEPS IN THE GIVEN ORDER. FAILURE TO DO SO
COULD RESULT IN SUBSTANTIAL PROPERTY DAMAGE, SEVERE PERSONAL
INJURY, OR DEATH.
WARNING
Improper installation, adjustment, alteration, service, or maintenance could
void product warranty and cause property damage, severe personal injury,
or death.
California Proposition 65 Warning: This product contains chemicals known
to the State of California to cause cancer, birth defects, or other reproductive
harm.
NOTICE
The manufacturer reserves the right to make product changes or updates
without notice and will not be held liable for typographical errors in literature.
The surfaces of these products contacted by potable (consumable) water
contain less than 0.25% lead by weight as required by the Safe Drinking Water
Act, Section 1417.
FTVN
FTVN
