The M/GE-xSW-SFP-01-xx-UxX series includes:
SKU
Enterprise Grade Converters (0°C to +50°C)
M/GE-PSW-SFP-01-UTX
M/GE-PSW-SFP-01-URX
Hardened Grade Converters (-40°C to +75°C)
M/GE-ISW-SFP-01-UTX
M/GE-ISW-SFP-01-URX
PoE-Powered Hardened Grade Converters (-40°C to +75°C)
M/GE-ISW-SFP-01-PD-UTX
M/GE-ISW-SFP-01-PD-URX
Power Supply Options
SPS-2460-SA
SPS-UA12DHT
25165
Mounting Options
WMBM
M-MCR-01
DRBM
RMBM
SFP Module Options
TN-xxXSFP-xxx
Note: Typical maximum cable distance. Actual distance depends on the physical characteristics of the network.
For more information, see https://www.transition.com/.
33781 Rev. B
10/100/1000Base-T (RJ-45) [100 m/328 ft.] to 100/1000Base-X SFP Slot
(empty) Uni-directional Transmitting Converter
10/100/1000Base-T (RJ-45) [100 m/328 ft.] to 100/1000Base-X SFP Slot
(empty) Uni-directional Receiving Converter
Hardened Mini 10/100/1000Base-T (RJ-45) to 100/1000Base-X Open SFP Slot
Uni-directional Transmitting Converter
Hardened Mini 10/100/1000Base-T (RJ-45) to 100/1000Base-X Open SFP Slot
Uni-directional Receiving Converter
PoE Powered Hardened Mini; 10/100/1000Base-T (RJ-45) to 100/1000Base-
X Open SFP Slot Uni-directional Transmitting Converter
PoE Powered Hardened Mini; 10/100/1000Base-T (RJ-45) to 100/1000Base-
X Open SFP Slot Uni-directional Receiving Converter
Power Supply, 24VDC to 60VDC input Stand-alone (for Enterprise
Converters) (must be ordered separately)
External AC/DC Desktop Power Supply, 12 VDC, 18W (for Hardened Non-PD
Converters)
Universal AC/DC Input DIN Rail Mountable +12 VDC Power Supply (for
Hardened Non-PD Converters)
Wall Mount Bracket for Mini (for Enterprise Converters)
18-Slot Powered Mini Chassis (for Enterprise Converters)
DIN Rail Mount Bracket for Mini (for Enterprise Converters)
Rack Mount Bracket for Mini, use with RMS19-SA4-02 and/or
E-MCR-05
These converters support dual speed 100/1000Mbps SFP modules.
Transition Networks offers a full line of small form factor pluggable (SFP)
transceivers; see our SFP
https://www.transition.com/
M-GE-xSW-SFP-01-xx-UxX Series User Guide
Description
webpage.
