4.2.7 System Signals

Use these CS181xx signals in the manner strictly described in the CS181xx reference
design. Each signal is briefly described below.
Signal
VCXO_CTRL
MCLK_SEL
DBDA, DBCK
TEST
DATA[15:0]
ADDR[19:0]
WE
CS1
CS2
OE
IOWAIT
GPIO[2:0]
XTI
XTO
XTAL_OUT
FILT2, FILT1
DAO_MCLK
HS[3:0]
DS651UM21
Version 2.1
Description
A Delta-sigma DAC Output for Controlling the On-board VCXO
Control Signal for Selecting MCLK Sources
I2C Debugger Interface
Used for testing during manufacturing. Keep grounded for normal
operation.
Data Bus for Flash & Ethernet Controller(s)
Address Bus for Flash & Ethernet Controller(s)
Write Enable for Flash and Ethernet Controller(s)
Chip Select for Flash Memory Device
Chip Select for Ethernet Controller(s)
Output Enable
Wait State Signal from Ethernet Controller(s)
General-purpose I/O Signals
Reference Clock Input / Crystal Oscillator Input
Crystal Oscillator Output
A Buffered Version of XTI
PLL Loop Filter
MCLK Input
CS181xx Boot Mode Selection
©
