Altronix AL1002ULADA Installation Manual page 6

Function
Amseco
Sync Mode*
®
Gentex
Sync Mode*
Gentex is a registered
trademark of
Gentex Corporation.
®
System Sensor
Sync Mode*
System Sensor is a
registered trademark of
Honeywell.
®
CooperWheelock
Sync Mode*
CooperWheelock is a
registered trademark of
Cooper Wheelock.
*Note: The AL1002ULADA/R1002ULADA will only synchronize horns, horn/strobes and strobes that contain
synchronization capability. The same synchronization mode must be selected for all outputs
Amount of Notification Appliances per NAC:
Amseco
Gentex ®
*Not to exceed a maximum of 2.5A per NAC.
Power Supply Board*
Terminal
Function/Description
Legend
L, N Connect 120VAC to these terminals: L to hot, N to neutral (Fig. 8, pg. 11).
+ DC – 24VDC @ 10A in alarm non power-limited output (Fig. 8, pg. 11).
Form "C" dry contacts used to instantaneously signal the loss AC to local annunciation devices,
AC FAIL
with AC present terminals marked NO and C are open, NC and C are closed. When loss of AC
NO, C, NC
occurs terminals marked NO and C are closed, NC and C are open.
Form "C" dry contacts used to instantaneously signal the loss AC to local annunciation devices,
AC LOCAL
with AC present terminals marked NO and C are open, NC and C are closed. When loss of AC
NC, NO, C
occurs terminals marked NO and C are closed, NC and C are open.
Form "C" dry contacts used to signal low battery voltage or loss of battery voltage. Under
BAT FAIL
normal conditions terminals marked NO and C are open, NC and C are closed. During a trouble
NO, C, NC
condition terminals marked NO and C are closed, and NC and C are open (Fig. 8, pg. 11).
– BAT + Stand-by battery input (leads provided) (Fig. 8, pg. 11).
*Power Board Parameter Specifications:
• AC Fail condition will report approximately 2 hours after loss of AC. To set AC Delay to 1 minute power
the unit down (AC supply and Battery) prior to changing switch position.
Turn "AC Delay" switch ON for 1 minute or OFF for 2 hours, respectively.
• Low battery condition will report at approximately 20VDC.
• Battery presence detection will report with in 180 seconds after battery remains undetected (missing or
removed). A restored battery will report within 30 seconds.
- 6 -
Sync Mode Selection Table:
Switch Positions
Descriptions
ON OFF
This mode is designed to work with the Amseco series of horns,
strobes, and horn/strobes to provide a means of synchronizing the
1, 3,
2 Temporal-coded horns, synchronizing the flash timing of the strobe,
4
and allowing audible notification appliances (horns) and visual notifi-
cation appliances (strobes) to be silenced/ deactivated at the same time.
This mode is designed to work with the Gentex
strobes, and horn/strobes to provide a means of synchronizing the
1, 2,
Temporal-coded horns, synchronizing the flash timing of the strobe,
3, 4
and allowing audible notification appliances (horns) and visual notifi-
cation appliances (strobes) to be silenced/ deactivated at the same time.
This mode is designed to work with the System Sensor
horns, strobes, and horn/strobes to provide a means of synchronizing
the Temporal-coded horns, synchronizing the one-second flash timing
1, 2, 4 3
of the strobe, and allowing audible notification appliances (horns) and
visual notification appliances (strobes) to be silenced/ deactivated at
the same time.
This mode is designed to work with the CooperWheelock series of
horns, strobes, and horn/strobes to provide a means of synchronizing
the Temporal-coded horns, synchronizing the one-second flash timing
2, 3, 4 1
of the strobe, and allowing audible notification appliances (horns) and
visual notification appliances (strobes) to be silenced/ deactivated at
the same time.
27 per NAC*
32 per NAC*
Terminal Identification Table:
System Sensor ®
CooperWheelock ®
32 per NAC*
32 per NAC*
AL1002ULADA / R1002ULADA
®
series of horns,
® series of
