- Page 1 AL1042ADA220 NAC Power Extender Installation Guide (see Application Guide for additional information) More than just power. Rev. 010814 Installing Company: _______________ Service Rep. Name: __________________________________ Address: _____________________________________________ Phone #: __________________...
-
Page 2: Specifications
Overview: Altronix AL1042ADA220 is an extremely cost-effective 10A remote power supply/battery charger. It may be con- nected to any 12 or 24 volt Fire Alarm Control Panel (FACP). Primary applications include Notification Appliance Circuit (NAC such as strobes and horns) expansion support to meet ADA requirements. It also provides auxiliary power to support system accessories. -
Page 3: Power Supply Specifications
Use two (2) 12VDC / 7AH or two (2) 12VDC / 12AH Battery batteries connected in series. Stand-by/Alarm 130mA/300mA Current Consumption: EOL Resistor (end of line): 2.2K (2200 Ohm), Altronix Model # AL-EOL22 (included). Ground fault maximum 1000 Ohm. test impedance: Stand-by Specifications: Stand-by Time Alarm Output Current Aux. - Page 4 Cooper Wheelock. nation over a two-wire circuit while leaving strobes active. *Note: AL1042ADA220 will only synchronize horns, horn/strobes, and strobes that contain synchronization capability. Contact signal manufacturer for more detailed info. The same synchronization mode must be selected for all outputs.
- Page 5 Battery Stand-by Specifications, pg. 3 for ratings. When loads are connected to the “AUX1” and or “AUX2” outputs during alarm condition, the remaining outputs may not exceed 10A total alarm current. Example: AUX1 = 1A, AUX2 = 1A, outputs up to 8A. AL1042ADA220 Installation Guide - 5 -...
-
Page 6: Led Diagnostics
To reset the memory depress the reset button located on the AL842LGK logic board (Fig. 2c, pg. 7). The LED(s) will extinguish. Note: When indicating circuits have restored, trouble memory reset is not required for normal operation. - 6 - AL1042ADA220 Installation Guide... - Page 7 C "FAU C "FAULT" NC C "FAULT" NC NC C NC C NO NC C NO NC C NC C NO NC C NO AL1042ADA220 Installation Guide - 7 -...
-
Page 8: Maintenance
Input fuse rating is 6.3A @ 250V, Output fuse rating is 15A @ 32V. Note: Maximum charging current is 1.5A. Note: Expected battery life is 5 years; however, it is recommended changing batteries in 4 years or less if needed. - 8 - AL1042ADA220 Installation Guide... -
Page 9: Battery Calculation Worksheet
(30% extra insurance to meet desired performance) Total ampere - hours required Units are capable of recharging 36AH battery max. If total ampere - hour required exceeds 36AH, decrease AUX current to provide enough stand-by time for the application. AL1042ADA220 Installation Guide - 9 -... -
Page 10: Appendix A - Compatible Devices
Appendix A - Compatible Devices –––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––– A-1 Four (4) Wire Smoke Detectors Table A-1 below lists four (4) wire smoke detectors compatible with AL1042ADA220 AUX output. Max Standby Alarm Smoke Detector/Base Detector Type Current (mA) Current (mA) FenWal CPD-7021 (w/70-201000-005 Base) Ionization 0.10... - Page 11 A-2 Door Holders –––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––– Table A-2 below lists door holders compatible with AL1042ADA220 AUX output. Manufacturer Model Type Current (mA) Edwards DH150A Floor Mount Edwards DH154A Floor Mount Edwards DH158A Surface Mount Rixon Firemark FM-980 Floor Mount, single Rixon Firemark...
-
Page 12: Enclosure Dimensions
4.5” (114.3mm) 4.5” (114.3mm) (69.9mm) (69.9mm) 14.5” (368.3mm) Altronix is not responsible for any typographical errors. –––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––– 140 58th Street, Brooklyn, New York 11220 USA | phone: 718-567-8181 | fax: 718-567-9056 website: www.altronix.com | e-mail: info@altronix.com | Lifetime Warranty IIAL1042ADA220...
