AL1002ADA220
NAC Power Extender
Installation Guide
(see Application Guide for additional information)
More than just power.
Rev. 010714
TM
Installing Company: _______________ Service Rep. Name: __________________________________
Address: _____________________________________________ Phone #: __________________
Advertisement
Table of Contents
Related Manuals for Altronix AL1002ADA220
Summary of Contents for Altronix AL1002ADA220
- Page 1 AL1002ADA220 NAC Power Extender Installation Guide (see Application Guide for additional information) More than just power. Rev. 010714 Installing Company: _______________ Service Rep. Name: __________________________________ Address: _____________________________________________ Phone #: __________________...
-
Page 2: Specifications
Overview: Altronix AL1002ADA220 is an extremely cost-effective 10A remote power supply/battery charger. It may be con- nected to any 12 or 24 volt Fire Alarm Control Panel (FACP). Primary applications include Notification Appliance Circuit (NAC such as strobes and horns) expansion support to meet ADA requirements. It also provides auxiliary power to support system accessories. -
Page 3: Power Supply Specifications
Use two (2) 12VDC batteries connected in series. Note: If batteries being used in your installation do not fit into the AL1002ADA220 unit, it is required to install a separate enclosure, UL Listed for appropriate application. Separate battery enclosure is required to have 50 cubic inches of additional open space. - Page 4 If additional battery enclosure is required, it must be UL Listed for the application and mounted within 5’ of the AL1002ADA220 enclosure in the same room; minimum 12 AWG wire in appropriate conduit is required for connection. When using conduit, make sure it is installed in a matter where it can not turn.
- Page 5 (strobes) to be silenced/ deactivated at of Cooper Wheelock. the same time. *Note: The AL1002ADA220 will only synchronize horns, horn/strobes and strobes that contain synchronization capability. Contact signal manufacturer for more detailed info. The same synchronization mode must be selected for all outputs Note: It is required to control visual notification appliances (strobes) via Input 1 (IN1) and audible notification appliances (horns) via Input 2 (IN2).
- Page 6 For loads connected to “AUX” please refer to battery “Stand-by Specifications”, pg. 3 for ratings. When loads are connected to “AUX” output during alarm condition, the remaining outputs may not exceed 10A total alarm current (example: AUX = 1A, outputs up to 10A). - 6 - AL1002ADA220 Installation Guide...
-
Page 7: Led Diagnostics
To reset the memory depress the reset button (Fig. 3c, pg. 8). The LED(s) will extinguish. Note: If indicating circuits have been restored, memory reset is not required for normal operation of the unit. AL1002ADA220 Installation Guide - 7 -... - Page 8 Connections (non power-limited) Signaling supervised Circuits from FACP (power-limited) supervised Fig. 2a Incorrect Wire Correct Wire Handling Handling External Jacketed Shield Wire Insulation Pull back Solid Copper external jacketed Conductors shield approx. 1/2”. - 8 - AL1002ADA220 Installation Guide...
- Page 9 BAT FAIL AC FAIL AL1002ADA220 Installation Guide - 9 -...
-
Page 10: Maintenance
Input fuse rating is 6.3A@ 250V, Output fuse rating is 15A @ 32V. Note: Maximum charging current is 1.5A. Note: Expected battery life is 5 years; however, it is recommended changing batteries in 4 years or less if needed. - 10 - AL1002ADA220 Installation Guide... -
Page 11: Battery Calculation Worksheet
(30% extra insurance to meet desired performance) Total ampere - hours required Units are capable of recharging 36AH battery max. If total ampere - hour required exceeds 36AH, decrease AUX current to provide enough stand-by time for the application. AL1002ADA220 Installation Guide - 11 -... -
Page 12: Appendix A: Compatible Ul/Cul Listed Devices For Synchronization
Appendix A: Compatible UL/cUL Listed Devices for Synchronization –––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––– A-1 Strobes, Horns, and Horn/Strobes Table A-1 below lists Strobes, Horns, and Horn/Strobes compatible with AL1002ADA220 NAC outputs. Gentex: GCS24CR - UL GCCB24PCR / W - UL GEC24-15/75WR - UL GCS24CW - UL... -
Page 13: System Sensor
Appendix A (cont’d): Compatible UL/cUL Listed Devices for Synchronization –––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––– A-1 Strobes, Horns, and Horn/Strobes (cont’d) Table A-1 below lists Strobes, Horns, and Horn/Strobes compatible with AL1002ADA220 NAC outputs. System Sensor: CHSR - UL P4R-SP - UL PC4RH-P - UL... - Page 14 Appendix A (cont’d): Compatible UL/cUL Listed Devices for Synchronization –––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––– A-1 Strobes, Horns, and Horn/Strobes (cont’d) Table A-1 below lists Strobes, Horns, and Horn/Strobes compatible with AL1002ADA220 NAC outputs. Cooper/Wheelock: 50-241575W-FR - UL/cUL E70-24MCW-FN - UL/cUL ET90-24MCCH-FN - UL/cUL LSTW-A* - UL/cUL...
-
Page 15: Appendix B - Ul Listed Compatible Devices
Appendix B - UL Listed Compatible Devices –––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––– B-1 Four (4) Wire Smoke Detectors Table B-1 below lists four (4) wire smoke detectors compatible with AL1002ADA220 AUX output and Outputs 1-8 when programmed as AUX. System Sensor Max Stand-by Alarm... - Page 16 1.5” 4.615” (117.2mm) 4.615” (117.2mm) (38.1mm) (38.1mm) Altronix is not responsible for any typographical errors. –––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––– 140 58th Street, Brooklyn, New York 11220 USA | phone: 718-567-8181 | fax: 718-567-9056 website: www.altronix.com | e-mail: info@altronix.com | Lifetime Warranty IIAL1002ADA220 H10U...
