Page 1: Installation Guide
AL1042UL2ADA NAC Power Extender Installation Guide (See Application Guide for additional information) Rev. 080306... - Page 2 AL1042UL2ADA - NAC Power Extender Overview: The Altronix AL1042UL2ADA is an extremely cost effective 10 amp voltage regulated remote power supply/battery charger. It may be connected to any 12 or 24 volt Fire Alarm Control Panel (FACP). Primary applications include Notification Appliance Circuit (NAC such as strobes and horns) expansion support to meet ADA requirements.
- Page 3 Drill the lower holes and install the three fasteners. Place the enclosure’s upper keyholes over the two upper screws. Install the two lower screws and make sure to tighten all screws (Enclosure Dimensions, pg. 10). Secure enclosure to earth ground. Carefully review: Application Guide (for AL642UL2ADA, AL842UL2ADA, AL1042UL2ADA) Power Supply Specifications (pg. 3) Stand-by Specifications (pg.
-
Page 4: Sync Mode
Note: The AL1042UL2ADA will only synchronize horns, horn strobes and strobes that contain synchronization capability. Contact signal manufacturer for more detailed info. The same synchronization mode must be selected for all outputs. - Page 5 “Stand-by Specifications” above for ratings. When loads are connected to the “AUX1” and or “AUX2” out- puts during alarm condition, the remaining outputs may, not exceed 10 amp total alarm current. (example: AUX1 = 1 amp, AUX2 = 1 amp, outputs up to 8 amp). AL1042UL2ADA - 5 -...
- Page 6 [OUT1-OUT4] will blink with a shorter and distinctly different duration. The green input LED(s) will be off (normal condition). To reset the memory depress the “reset” button. The LED’s will extinguish. Note: If indicating circuits have been restored, memory reset is not required for normal operation of the unit. - 6 - AL1042UL2ADA...
- Page 7 “AUX2” will remain operational during allowable power failure. Refer to stand-by chart for stand-by and alarm current. Ground Fault Detect: Factory set disabled (Fig. 2A). To enable ground fault detection remove insulating washer between the board and standoff of the lower right power supply board mounting screw (Fig. 2B). AL1042UL2ADA - 7 -...
- Page 8 [- BAT +] to insure there is no break in the battery connection wires. Note: Maximum charging current is 3.2 amp. Note: Expected battery life is 5 years, however it is recommended changing batteries in 4 years or less if needed. - 8 - AL1042UL2ADA...
- Page 9 Number of Current per Device Stand-by Alarm Devices Current Current For each device use this formula: This column x This column = Equals Current per number of devices. AL1042UL2ADA Stand-by: 90mA 90mA (Current draw from battery) Alarm: 175mA 175mA 90mA...
- Page 10 Enclosure Dimensions: 18”H x 14.5”W x 4.625”D 14.50" 1.50" 2.50" 1.50" 2.50" 1.50" 1.25" 1.00" 1.25" 1.00" 1.00" 1.50" 1.50" 2.50" 8.50" 6.00" 18.00" 18.00" 18.00" 1.00" 1.00" 1.50" 1.00" 14.50" 2.75" 4.50" 4.50" 2.75" - 10 - AL1042UL2ADA...
- Page 11 Notes AL1042UL2ADA - 11 -...
- Page 12 Notes: Altronix is not responsible for any typographical errors. 140 58th Street, Brooklyn, New York 11220 USA, 718-567-8181, fax: 718-567-9056 web site: www.altronix.com, e-mail: info@altronix.com, Lifetime Warranty, Made in U.S.A. IIAL1042UL2ADA J26G MEMBER - 12 - AL1042UL2ADA...
