Connecting the optional monitor

Incorrect routing of the connection cables can cause
tripping, broken bones, bruises and crushing.
➢ Lay the connection cables so that no one can trip over
To connect an optional monitor, follow the steps below:
➢ Connect the DisplayPort connector of the monitor to the DisplayPort
connector on the back of the scanner.

Connecting the optional touch screen

Incorrect routing of the connection cables can cause
tripping, broken bones, bruises and crushing.
➢ Lay the connection cables so that no one can trip over
To connect an optional touch screen, follow these steps:
➢ Connect the DisplayPort connector of the touchscreen to the
DisplayPort connector jack on the back of the scanner.
➢ Connect the USB connector of the touchscreen to the USB connector on
the back of the scanner.
them.
them.
CAUTION
CAUTION
