Description

Overview back side

The following figure shows the back of the scanner.
No.
Designation
1
Main power switch
2
Connection socket 24 V DC for external power adapter
3
Network connection socket
4
DisplayPort connector socket
5
USB connection socket
6
Connection socket for foot switch
7
Four cylinder bolts with shaft collars for height adjustment
14
