■[F 3] Digital filter setting
Set the digital filter.
Output chattering or flicker in the measurement mode display can be reduced by setting the digital filter.
<Operation>
Press the UP or DOWN button in function selection mode to display [F 3].
Digital filter setting
Press the UP or DOWN button to select the digital filter value.
Press the SET button to set.
∗1: Each set value is a guideline for 90% response time.
∗2: Both the switch output and flow display are affected. When only switch output needs to be affected, select the delay time setting.
(page 42)
Press the SET button.
[F 3] Response time setting is completed.
-52-
Move on to digital filter setting.
Return to function selection mode.
No.PF※※-OMZ0002
