1.2 Product Overview

mini is a "mini" signal switcher and mixer which is able to stream 6-picture PVW or PGM from any one out of the 4
HDMI inputs to any live broadcasting platform via third party live streaming software such as OBS. It adopts
compact design, equipped with a 2 inch TFT screen to preview the 4 inputs in real time. 14 transition effects on
board work with T-Bar to do transition switching. Along with seamless switching, there are other outstanding
features such as audio embedding, de-embedding,and automatically identifying color depth of RGB4:4:4,
YUV4:4:4, YUV4:2:2, YUV4:2:0. mini devices are easy to operate either on board or remotely from mobile devices
or laptops with XPOSE mini.
1.2.1 Key Features
● USB3.0 live streaming Port
● 4CH HDMI inputs
● 2''TFT display on board to Live preview four inputs
● Auto cut and manual switch (T-Bar)
● 14 transition effects on T-Bar
● Support PIP（Picture-In-Picture)
● Audio offers AFV or Line In mode.
● Support switch between 6-Picture PVW and PGM to HDMI Out
● Control by PC or mobile phone (via APP)
