In T-BAR Mode:
Press a green button to set the source as the PVW, the source button will blink green.
Slide the T-BAR to switch/mix from the current PGM source to the PVW source.Any MIX
transition effect will be applied as the T-BAR is moved. Once the T-BAR has been fully transitioned, the indicator
lights on sources buttons that are PGM and PVW will be swapped.
1.Press a source button (1, 2, 3, or 4)
that is green.
Note: Source selection is locked when T-BAR is in transition (not entirely docked at a left or right position)
mini
2.Slide T-Bar from left end to right end
or reversely.
