FIRST IP ADDR
000.000.000.000
FIRST IP PORT
2001
SECOND IP ADDR
000.000.000.000
SECOND IP PORT
2001

NETWORK OPTIONS

Network options are provided to define the network configuration for the communicator. This information will be used
during communication of messages via network.
Note: IP addresses and port numbers may need to be assigned by the network administrator. When entering an IP,
gateway, or subnet mask address, be sure to enter all 12 digits and leave out the periods. For example, IP address
192.168.000.250 is entered as 192168000250.
DHCP
NO YES
LOCAL IP ADDR
192.168.0.250
GATEWAY ADDR
192.168.0.1
SUBNET MASK
255.255.255.0
DNS SERVER
0.0.0.0
PROGRAMMING
PORT
2001
iCom Series Universal Alarm Communicator Programming and Installation Guide
FIRST IP ADDRESS
Enter the first (primary) IP address where the communicator sends cell messages. Enter
all 12 digits and leave out the periods. For example, enter IP address 192.168.0.250 as
192168000250. The periods display automatically.
FIRST IP PORT
Enter the first IP port number to be used with the first IP address. The IP port identifies the
port used to communicate messages with the panel. The default IP port setting is 2001.
SECOND IP ADDRESS
Enter the second IP address where the communicator sends network messages. Enter all
12 digits and leave out the periods. The periods display automatically.
SECOND IP PORT
Enter the second IP port number to be used with the second IP address. The IP port
identifies the port used to communicate messages with the panel. The default IP Port
setting is 2001.
DHCP MODE ENABLED
Choose YES if the communicator uses a dynamic IP address. The communicator will
operate in DHCP and will not use the local IP address number. The default is YES.
Choose NO to have the communicator use the IP address entered in local IP address.
LOCAL IP ADDRESS
Enter the local IP address for the communicator. The local IP address must be unique and
cannot be duplicated on the network. The default local IP address is 192.168.0.250.
GATEWAY ADDRESS
Enter the local gateway address. The gateway IP address is needed to exit the local
network. The default gateway address is 192.168.0.1.
SUBNET MASK
Enter the local subnet mask assigned to the communicator. The default subnet mask
address is 255.255.255.000.
DNS SERVER
Enter the IP address of the DNS (Domain Name System) used by the communicator to
resolve domain names into IP addresses. The default address is 0.0.0.0.
PROGRAMMING PORT
Enter the programming port number. The programming port identifies the port used to
communicate messages to and from the communicator. The default programming port
setting is 2001.
Digital Monitoring Products
19
